Mobile crushing station

Mobile crushing station

Introduction to Mobile Crushing Station:

The mobile crushing station products designed and produced by Phoenix have a wide range of applications, including mining and crushing stone processing, construction waste recycling, finished aggregates, machine-made sand, refractory materials, building materials cement, roads and bridges, highways, mining and crushing stone processing, finished aggregate machine-made sand, and other occasions.

Advantages and Characteristics:

1. Curve crushing chamber: Based on the principle of material lamination crushing and the wear characteristics of the chamber wall, the chamber type is designed as a curve, which can ensure the goal of high crusher output, high product quality, and low wear cost.

2. The main crusher adopts an automatic control system, which has fully automatic crushing process control, one key automatic start, and advanced fault diagnosis functions. It can achieve overload or over iron protection for crushing operations, automatic compensation for liner wear, and other functions.

3. Adjustable eccentricity: The main crusher has an eccentric liner and a combination of eccentric liners. By rotating the eccentric liner, multiple eccentricity settings can be easily achieved to meet the requirements of different ores and mining industries.

4. Advanced hydraulic lubrication system: The main crusher lubrication system and hydraulic system are designed with modular modules, each operating independently and capable of protecting against oil temperature, flow rate, pressure, power, abnormal power supply, and other factors.

5. Convenient transportation: This type of mobile crushing station, due to its reasonable weight and appearance design, can be remotely controlled by a remote control module to transport up and down flatbed trailers, achieving long-distance transportation and easy transition operations.

The Phoenix Mobile Crushing Station is not just a technological product, it represents a new trend in crushing solutions. This solution is rapidly becoming the preferred choice for improving production efficiency and reducing costs in the mining and construction industries. The design concept of the mobile crushing station is to integrate crushing, screening, and conveying processes into a compact modular system, enabling it to be quickly deployed in various work sites, whether in open-pit mines or urban construction sites.

The adjustable eccentricity design of the mobile crushing station enables it to flexibly adapt to ore crushing under different hardness and humidity conditions, further expanding its application range. Its lightweight transportation and installation characteristics also enable the equipment to quickly adapt to the transfer between different construction sites, greatly improving construction efficiency.

Mobile crushing station parameters:

ModelFKHP2RSFKHP3RS
Feeding Equipment
Capacity(t/h)300400
Hopper Volume(m3)44
Feeding Belt Conveyor
L x W(mm)6000*10006600*1000
Feeding Height(mm)26002700
Motor(kw)7.57.5
Cone Crusher
ModelHP200HP300
Max Feeding Size(mm)185211
Close Side Setting(mm)10-3813-51
Motor(kw)132220
Main Belt Conveyor
SpecificationB1000x11.7MB1000x11.7M
Unloading Height(mm)33003300
Motor(kw)5.5*25.5*2
Final Product Belt Conveyor
SpecificationB1400x5.7MB1400x5.7M
Unloading Height(mm)30003000
(Motor((kw)7.57.5
Vibrating Screen
Lxw (mm)5000x17005000x1700
Motor(kw)4.35x24.35x2
Transition Belt Conveyor
SpecificationB500 x2.5MB500 x2.5M
Motor(kw)33
Returning Belt Conveyor
SpecificationB600x10.3MB600x10.3M
Motor(kw)5.57.5
Whole Plant
Driving Motor(kw)92,36092,360
Total weight(t)4260.5,62.5
Capacity(t/h)95-225110-360

Service and Support:

Phoenix not only provides high-quality mobile crushing station equipment, but also offers comprehensive after-sales service and technical support. From equipment installation and debugging, operation training to long-term maintenance, Phoenix's professional team will provide customers with continuous and stable services to ensure the long-term efficient operation of equipment.
